MicroLED Inspection & Testing for Automotive Displays
Automotive-grade microLED starts at the wafer. Reliability, readability in sunlight, and long life – screened and assured before modules are built.
For High Brightness & Harsh Environments
In-vehicle displays must remain legible in bright ambient light (often ~2000 nits or higher for sunlight readability), which means the internal projecter must reach levels approaching 15,000 nits. They also face harsh thermal/humidity/vibration environments governed by standards such as ISO 16750 (climatic loads) and AEC-Q reliability for optoelectronics.
MicroLED Challenges for Automotive Displays
MicroLED automotive displays must deliver extreme brightness while maintaining long-term reliability under the heat, humidity, vibration, and stringent qualification standards of the vehicle environment.
Wide Temperatures, Wide Instability
Wide temperature ranges (e.g., −40 °C up to 85 °C or more depending on location/grade) stress LED wavelength and output stability.
Tiny Variations, Visible Flaws
Uniformity & aging across larger display areas; tiny emitter variability becomes visible as mura/hot/cold pixels.
Qualification Demands, Statistical Proof
Traceability and lot-level statistics for qualification against automotive reliability standards
InZiv’s Solutions
InZiv provides a comprehensive inspection and metrology solution for microLEDs, spanning in-depth characterization, high-throughput data collection, and production-level inspection.
microLED Production at Scale
R-EL Glide
Rapidly inspects wafers at production scale (up to 6M LEDs/hour) and provides IV, LIV, EQE, and pass/fail logic for early-life failure detection. Non-damaging contact probing ensures high reliability and repeatability while preserving delicate emitter pads.
Turn-Key Metrology for R&D
OmniPix 3.0
Ensures wavelength and luminance stability with <1 nm spectral resolution across wafers, mapping PL/EL intensity and spectrum to identify outliers. The thermal chuck (up to 100 °C) enables characterization under conditions approaching ISO 16750 and AEC-Q test regimes. Angular emission measurement (±70°) correlates optical performance with structural reliability.
Why It Matters
Automotive programs demand sunlight-readable, durable displays and rigorous qualification (ISO 16750, AEC-Q102). Screening at the wafer stage reduces cost and risk downstream, improving yield and lifetime stability.
Identifying issues early in the wafer flow reduces downstream loss and supports the demands of automotive displays, built to endure heat, vibration, and years of continuous use.
Technical Specifications
The table below outlines representative performance targets used to illustrate inspection challenges; actual requirements vary by application and system design.
| Parameter | Example Performance Requirement | How InZiv Measures & Enables |
|---|---|---|
| Brightness | Up to 15,000 nits from projector for HUD | OmniPix captures IV, LIV, EQE at high drive currents. |
| Operating temperature | −40 °C to +85/125 °C | Thermal chuck (10–100 °C) enables reliability testing close to automotive ranges. |
| Wavelength stability | <1–2 nm drift | OmniPix’s <1 nm spectral resolution detects wavelength shifts. |
| Defect tolerance | <1 ppm dead pixels | R-EL Glide screens up to 6M LEDs/hour with pass/fail EL, feeding yield/repair. |
